STP3N80K5
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 800V 2.5A TO220
PDF
/
Buying Options
Total Price: USD $1.33
Unit Price: USD $1.3288
≥1 USD $1.3288
≥10 USD $1.070432
≥100 USD $0.880792
≥500 USD $0.74529
≥1000 USD $0.632359
≥3000 USD $0.60075
Inventory: 1200
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 15.75mm
Technical
Avalanche Energy Rating (Eas) 65 mJ
DS Breakdown Voltage-Min 800V
Gate to Source Voltage (Vgs) 30V
JEDEC-95 Code TO-220AB
Continuous Drain Current (ID) 2.5A
Turn-Off Delay Time 20.5 ns
Fall Time (Typ) 25 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 800V
Rise Time 7.5ns
Gate Charge (Qg) (Max) @ Vgs 9.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 2.5A Tc
Input Capacitance (Ciss) (Max) @ Vds 130pF @ 100V
Vgs(th) (Max) @ Id 5V @ 100μA
Rds On (Max) @ Id, Vgs 3.5 Ω @ 1A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 8.5 ns
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 60W Tc
Number of Channels 1
Number of Elements 1
Base Part Number STP3N
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series SuperMESH5?
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 329.988449mg
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status NRND (Last Updated: 7 months ago)
