STP265N6F6AG
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 60V 180A TO220
PDF
/
Buying Options
Total Price: USD $66.36
Unit Price: USD $66.35845
≥1 USD $66.35845
≥10 USD $54.4483
≥100 USD $52.74685
≥500 USD $51.0454
≥1000 USD $49.34395
Inventory: 1598
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Continuous Drain Current (ID) 180A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 60V
Gate Charge (Qg) (Max) @ Vgs 183nC @ 10V
Current - Continuous Drain (Id) @ 25°C 180A Tc
Input Capacitance (Ciss) (Max) @ Vds 11800pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 2.85m Ω @ 60A, 10V
FET Type N-Channel
Power Dissipation-Max 300W Tc
Configuration Single
Base Part Number STP265
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, STripFET? F6
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 38 Weeks
