STP260N4F7
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CHANNEL 40V 120A TO220
PDF
/
Buying Options
Total Price: USD $1.75
Unit Price: USD $1.75085
≥1 USD $1.75085
≥10 USD $1.4364
≥100 USD $1.39175
≥500 USD $1.3471
≥1000 USD $1.30245
Inventory: 1344
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 40V
Gate Charge (Qg) (Max) @ Vgs 67nC @ 10V
Current - Continuous Drain (Id) @ 25°C 120A Tc
Input Capacitance (Ciss) (Max) @ Vds 5600pF @ 25V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 2.2m Ω @ 60A, 10V
FET Type N-Channel
Power Dissipation-Max 235W Tc
Base Part Number STP260
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series STripFET?
Operating Temperature -55°C~175°C TJ
Physical
Package / Case TO-220-3
Mounting Type Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 22 Weeks
