STL9P2UH7
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerVDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET POWER MOSFET
PDF
/
Buying Options
Total Price: USD $0.32
Unit Price: USD $0.3192
≥1 USD $0.3192
≥10 USD $0.2622
≥100 USD $0.25365
≥500 USD $0.24605
≥1000 USD $0.2375
Inventory: 1202
Minimum: 1
-
+
Technical Details
Technical
Drive Voltage (Max Rds On,Min Rds On) 1.5V 4.5V
Vgs (Max) ±8V
Fall Time (Typ) 84.5 ns
Turn-Off Delay Time 128 ns
Continuous Drain Current (ID) 9A
Gate to Source Voltage (Vgs) 8V
Drain to Source Breakdown Voltage 20V
Rise Time 30.5ns
Gate Charge (Qg) (Max) @ Vgs 22nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 9A Tc
Input Capacitance (Ciss) (Max) @ Vds 2390pF @ 16V
Vgs(th) (Max) @ Id 1V @ 250μA
Rds On (Max) @ Id, Vgs 22.5m Ω @ 4.5A, 4.5V
FET Type P-Channel
Turn On Delay Time 12.5 ns
Power Dissipation-Max 2.9W Tc
Base Part Number STL9
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Resistance 19.5mOhm
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Series STripFET?
Packaging Cut Tape (CT)
Operating Temperature 150°C TJ
Compliance
RoHS Status ROHS3 Compliant
Physical
Number of Pins 8
Package / Case 8-PowerVDFN
Mounting Type Surface Mount
Mount Surface Mount
