VF20200G-E3/4W
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack, Isolated Tab
Category Discrete Semiconductor Products / Diodes - Rectifiers - Arrays
Description
Schottky Diodes & Rectifiers 20 Amp 200 Volt Dual 110 Amp IFSM
PDF
/
Buying Options
Total Price: USD $1.32
Unit Price: USD $1.32
≥1 USD $1.32
≥10 USD $1.09384
≥100 USD $0.870936
≥500 USD $0.73693
≥1000 USD $0.625275
≥3000 USD $0.594009
Inventory: 1182
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Diode Configuration 1 Pair Common Cathode
Peak Non-Repetitive Surge Current 110A
JEDEC-95 Code TO-220AB
Max Repetitive Reverse Voltage (Vrrm) 200V
Peak Reverse Current 150μA
Number of Phases 1
Average Rectified Current 10A
Max Reverse Voltage (DC) 200V
Forward Voltage 1.7V
Application EFFICIENCY
Max Surge Current 110A
Operating Temperature - Junction -40°C~150°C
Max Reverse Leakage Current 150μA
Forward Current 20A
Voltage - Forward (Vf) (Max) @ If 1.7V @ 10A
Current - Reverse Leakage @ Vr 150μA @ 200V
Diode Type Schottky
Speed Fast Recovery =< 500ns, > 200mA (Io)
Element Configuration Common Cathode
Number of Elements 2
Pin Count 3
Terminal Position SINGLE
Subcategory Rectifier Diodes
HTS Code 8541.10.00.80
Additional Feature FREE WHEELING DIODE, LOW POWER LOSS
Min Operating Temperature -40°C
Max Operating Temperature 150°C
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Series TMBS?
Published 2011
Packaging Tube
Physical
Diode Element Material SILICON
Number of Pins 3
Package / Case TO-220-3 Full Pack, Isolated Tab
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Factory Lead Time 10 Weeks
