STL23NM50N
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerVDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-Ch 500V 0.170Ohm 14A pwr MOSFET
PDF
/
Buying Options
Total Price: USD $1.09
Unit Price: USD $1.093444
≥1 USD $1.093444
≥10 USD $1.052339
Inventory: 1098
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Technical
Drain to Source Breakdown Voltage 550V
Gate to Source Voltage (Vgs) 25V
Continuous Drain Current (ID) 14A
Turn-Off Delay Time 71 ns
Fall Time (Typ) 29 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 500V
Rise Time 19ns
Gate Charge (Qg) (Max) @ Vgs 45nC @ 10V
Current - Continuous Drain (Id) @ 25°C 2.8A Ta 14A Tc
Input Capacitance (Ciss) (Max) @ Vds 1330pF @ 50V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 210m Ω @ 7A, 10V
FET Type N-Channel
Turn On Delay Time 6.6 ns
Power Dissipation 3W
Element Configuration Single
Power Dissipation-Max 3W Ta 125W Tc
Base Part Number STL23
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Active
Series MDmesh? II
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Package / Case 8-PowerVDFN
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status NRND (Last Updated: 8 months ago)
