STI360N4F6
RoHS
RoHS compliant
RoHS compliantPackage TO-262-3 Long Leads, I2Pak, TO-262AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 40V 120A I2PAK
PDF
/
Inventory: 1451
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 120A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 40V
Gate Charge (Qg) (Max) @ Vgs 340nC @ 10V
Current - Continuous Drain (Id) @ 25°C 120A Tc
Input Capacitance (Ciss) (Max) @ Vds 17930pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Rds On (Max) @ Id, Vgs 1.8m Ω @ 60A, 10V
FET Type N-Channel
Element Configuration Single
Power Dissipation-Max 300W Tc
Number of Channels 1
Base Part Number STI360N
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Powers
ECCN Code EAR99
Moisture Sensitivity Level (MSL) Not Applicable
Part Status Obsolete
Series Automotive, AEC-Q101, DeepGATE?, STripFET? VI
Packaging Tube
Operating Temperature -55°C~175°C TJ
Physical
Weight 1.437803g
Number of Pins 3
Package / Case TO-262-3 Long Leads, I2Pak, TO-262AA
Mounting Type Through Hole
Mount Through Hole
