STH315N10F7-2
RoHS
RoHS compliant
RoHS compliantPackage TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET, N CH, 100V, 180A, H2PAK-3
PDF
/
Buying Options
Total Price: USD $4.86
Unit Price: USD $4.8576
≥1 USD $4.8576
≥10 USD $4.0788
≥100 USD $3.299648
≥500 USD $2.93304
Inventory: 931
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Technical
Pulsed Drain Current-Max (IDM) 720A
Drain to Source Breakdown Voltage 100V
Gate to Source Voltage (Vgs) 20V
Threshold Voltage 3.5V
Continuous Drain Current (ID) 180A
Turn-Off Delay Time 148 ns
Fall Time (Typ) 40 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 108 ns
Gate Charge (Qg) (Max) @ Vgs 180nC @ 10V
Current - Continuous Drain (Id) @ 25°C 180A Tc
Input Capacitance (Ciss) (Max) @ Vds 12800pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 250μA
Rds On (Max) @ Id, Vgs 2.3m Ω @ 60A, 10V
Transistor Application SWITCHING
FET Type N-Channel
Turn On Delay Time 62 ns
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 315W Tc
Number of Channels 1
Number of Elements 1
JESD-30 Code R-PSSO-G2
Base Part Number STH315
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Additional Feature ULTRA LOW RESISTANCE
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series Automotive, AEC-Q101, DeepGATE?, STripFET? VII
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Weight 3.949996g
Number of Pins 3
Package / Case TO-263-3, D2Pak (2 Leads + Tab), TO-263AB
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
