STF40N65M2
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 650V 32A TO220FP
PDF
/
Buying Options
Total Price: USD $10.55
Unit Price: USD $10.55165
≥1 USD $10.55165
≥10 USD $8.6583
≥100 USD $8.38755
≥500 USD $8.1168
≥1000 USD $7.84605
Inventory: 1904
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Dimensions
Width 4.6mm
Length 10.4mm
Height 16.4mm
Technical
Gate to Source Voltage (Vgs) 25V
Continuous Drain Current (ID) 32A
Turn-Off Delay Time 96.5 ns
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 650V
Gate Charge (Qg) (Max) @ Vgs 56.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 32A Tc
Input Capacitance (Ciss) (Max) @ Vds 2355pF @ 100V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 99m Ω @ 16A, 10V
FET Type N-Channel
Turn On Delay Time 15 ns
Element Configuration Single
Power Dissipation-Max 25W Tc
Base Part Number STF40N
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? M2
Packaging Tube
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 7 months ago)
Factory Lead Time 16 Weeks
