STF11N50M2

STMicroelectronics
RoHS
RoHS RoHS compliant
Package TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description MOSFET N-CH 500V 8A TO220FP
PDF
/
Buying Options
Total Price: USD $1.17
Unit Price: USD $1.1704
≥1 USD $1.1704
≥10 USD $0.942128
≥100 USD $0.746592
Inventory: 236
Minimum: 1
-
+

Technical Details

Compliance

Lead Free Lead Free
RoHS Status ROHS3 Compliant

Technical

Continuous Drain Current (ID) 8A
Vgs (Max) ±25V
Drive Voltage (Max Rds On,Min Rds On) 10V
Drain to Source Voltage (Vdss) 500V
Gate Charge (Qg) (Max) @ Vgs 12nC @ 10V
Current - Continuous Drain (Id) @ 25°C 8A Tc
Input Capacitance (Ciss) (Max) @ Vds 395pF @ 100V
Vgs(th) (Max) @ Id 4V @ 250μA
Rds On (Max) @ Id, Vgs 530m Ω @ 4A, 10V
FET Type N-Channel
Power Dissipation-Max 25W Tc
Base Part Number STF11
Technology MOSFET (Metal Oxide)
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series MDmesh? II Plus
Packaging Tube
Operating Temperature -55°C~150°C TJ

Physical

Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole

Supply Chain

Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 16 Weeks
