Element Configuration Single
Operating Mode ENHANCEMENT MODE
Turn On Delay Time 9.2 ns
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 1.8 Ω @ 1.5A, 10V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Input Capacitance (Ciss) (Max) @ Vds 305pF @ 25V
Current - Continuous Drain (Id) @ 25°C 3A Tc
Gate Charge (Qg) (Max) @ Vgs 17nC @ 10V
Drive Voltage (Max Rds On,Min Rds On) 10V
Turn-Off Delay Time 22.5 ns
Continuous Drain Current (ID) 3A
Gate to Source Voltage (Vgs) 30V
Drain Current-Max (Abs) (ID) 3A
Drain to Source Breakdown Voltage 400V
Power Dissipation-Max 45W Tc
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Technology MOSFET (Metal Oxide)
Subcategory FET General Purpose Power
Terminal Finish Matte Tin (Sn)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
