STD1NK80ZT4
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 800V 1A 3-Pin(2+Tab) DPAK T/R
PDF
/
Buying Options
Total Price: USD $0.95
Unit Price: USD $0.9504
≥1 USD $0.9504
≥10 USD $0.7744
≥100 USD $0.602096
≥500 USD $0.510382
≥1000 USD $0.415756
Inventory: 2507
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 12 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Number of Pins 3
Transistor Element Material SILICON
Manufacturer Package Identifier TO-252-P032P
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series SuperMESH?
JESD-609 Code e3
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Resistance 16Ohm
Terminal Finish Matte Tin (Sn) - annealed
Subcategory FET General Purpose Power
Voltage - Rated DC 800V
Technology MOSFET (Metal Oxide)
Terminal Form GULL WING
Peak Reflow Temperature (Cel) 260
Current Rating 1A
Time@Peak Reflow Temperature-Max (s) 30
Base Part Number STD1NK
Pin Count 3
JESD-30 Code R-PSSO-G2
Number of Elements 1
Number of Channels 1
Power Dissipation-Max 45W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 45W
Turn On Delay Time 8 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 16 Ω @ 500mA, 10V
Vgs(th) (Max) @ Id 4.5V @ 50μA
Input Capacitance (Ciss) (Max) @ Vds 160pF @ 25V
Current - Continuous Drain (Id) @ 25°C 1A Tc
Gate Charge (Qg) (Max) @ Vgs 7.7nC @ 10V
Rise Time 30 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 55 ns
Turn-Off Delay Time 22 ns
Continuous Drain Current (ID) 1A
Threshold Voltage 3.75V
JEDEC-95 Code TO-252AA
Gate to Source Voltage (Vgs) 30V
Drain Current-Max (Abs) (ID) 1A
Drain to Source Breakdown Voltage 800V
Pulsed Drain Current-Max (IDM) 5A
Avalanche Energy Rating (Eas) 50 mJ
Max Junction Temperature (Tj) 150°C
Dimensions
Height 2.4mm
Length 6.6mm
Width 6.2mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
