RW1A020ZPT2R
RoHS
RoHS compliant
RoHS compliantPackage /
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 12V 2A WEMT6
PDF
/
Buying Options
Total Price: USD $9.27
Unit Price: USD $9.272
≥1 USD $9.272
≥10 USD $7.6076
≥100 USD $7.3701
≥500 USD $7.1326
≥1000 USD $6.8951
Inventory: 1242
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 10 Weeks
Physical
Mount Surface Mount
Number of Pins 6
Technical
Packaging Tape & Reel (TR)
Published 2009
JESD-609 Code e2
Pbfree Code yes
Part Status Not For New Designs
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 6
ECCN Code EAR99
Terminal Finish Tin/Copper (Sn/Cu)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Subcategory Other Transistors
Max Power Dissipation 700mW
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 10
Pin Count 6
Number of Elements 1
Configuration SINGLE WITH BUILT-IN DIODE
Number of Channels 1
Operating Mode ENHANCEMENT MODE
Turn On Delay Time 10 ns
Transistor Application SWITCHING
Rise Time 17ns
Drain to Source Voltage (Vdss) 12V
Polarity/Channel Type P-CHANNEL
Fall Time (Typ) 35 ns
Turn-Off Delay Time 65 ns
Continuous Drain Current (ID) 2A
Gate to Source Voltage (Vgs) 10V
Drain Current-Max (Abs) (ID) 2A
Drain to Source Breakdown Voltage -12V
Input Capacitance 770pF
FET Technology METAL-OXIDE SEMICONDUCTOR
Drain to Source Resistance 75mOhm
Rds On Max 105 mΩ
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
Lead Free Lead Free
