UPA2720GR-E1-A image
Favorite
UPA2720GR-E1-A image
Favorite
RoHS
RoHS RoHS compliant
Package 8-SOIC (0.173, 4.40mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description POWER, 14A, 30V, N-CH MOSFET
PDF
/
Buying Options
Total Price: USD $1
Unit Price: USD $1.0032
≥1 USD $1.0032
Inventory: 1142
Minimum: 1
-
+

Technical Details

Physical

Mounting Type Surface Mount
Package / Case 8-SOIC (0.173, 4.40mm Width)
Supplier Device Package 8-PSOP

Technical

Packaging Tape & Reel (TR)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
FET Type N-Channel
Rds On (Max) @ Id, Vgs 6.6mOhm @ 7A, 10V
Vgs(th) (Max) @ Id 2.5V @ 1mA
Input Capacitance (Ciss) (Max) @ Vds 2.8pF @ 10V
Current - Continuous Drain (Id) @ 25°C 14A Ta
Gate Charge (Qg) (Max) @ Vgs 27nC @ 5V
Drain to Source Voltage (Vdss) 30V

Compliance

RoHS Status ROHS3 Compliant
