SFT1431-E
RoHS
/
Package TO-251-3 Short Leads, IPak, TO-251AA
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET NCH 4V DRIVE SERIES
PDF
/
Inventory: 6082
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
Drain to Source Breakdown Voltage 35V
Gate to Source Voltage (Vgs) 20V
Continuous Drain Current (ID) 11A
Turn-Off Delay Time 60 ns
Fall Time (Typ) 36 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4V 10V
Rise Time 40ns
Gate Charge (Qg) (Max) @ Vgs 17.3nC @ 10V
Current - Continuous Drain (Id) @ 25°C 11A Ta
Input Capacitance (Ciss) (Max) @ Vds 960pF @ 20V
Rds On (Max) @ Id, Vgs 25m Ω @ 5.5A, 10V
FET Type N-Channel
Turn On Delay Time 12 ns
Power Dissipation 1W
Power Dissipation-Max 1W Ta 15W Tc
Pin Count 3
Technology MOSFET (Metal Oxide)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Published 2012
Packaging Bulk
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-251-3 Short Leads, IPak, TO-251AA
Mounting Type Through Hole
Mount Through Hole
