2SB1302T-TD-E
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT PNP 20V 5A 4-Pin(3+Tab) PCP T/R
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.1349
≥1 USD $0.1349
≥10 USD $0.1102
≥100 USD $0.10735
≥500 USD $0.10355
≥1000 USD $0.1007
Inventory: 1189
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
Dimensions
Width 2.5mm
Length 4.5mm
Height 1.5mm
Technical
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 25V
Collector Emitter Saturation Voltage -500mV
Transition Frequency 320MHz
Current - Collector (Ic) (Max) 5A
Collector Emitter Breakdown Voltage 20V
Vce Saturation (Max) @ Ib, Ic 500mV @ 60mA, 3A
Current - Collector Cutoff (Max) 500nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 500mA 2V
Max Collector Current 5A
Collector Emitter Voltage (VCEO) 10V
Transistor Type PNP
Polarity/Channel Type PNP
Transistor Application SWITCHING
Case Connection COLLECTOR
Power Dissipation 1.3W
Element Configuration Single
Number of Elements 1
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Frequency 320MHz
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Max Power Dissipation 1.3W
Subcategory Other Transistors
Terminal Finish Tin/Bismuth (Sn/Bi)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e6
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Surface Mount YES
Package / Case TO-243AA
Mounting Type Surface Mount
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 5 days ago)
Factory Lead Time 2 Weeks
