FDA59N30
RoHS
RoHS compliant
RoHS compliantPackage TO-3P-3, SC-65-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 300V 59A TO-3P
PDF
/
Buying Options
Total Price: USD $3.66
Unit Price: USD $3.6608
≥1 USD $3.6608
≥10 USD $2.90019
≥100 USD $2.48585
≥500 USD $2.209627
≥1000 USD $1.891991
≥3000 USD $1.781516
Inventory: 682
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 7 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-3P-3, SC-65-3
Number of Pins 3
Weight 6.401g
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tube
Published 2013
Series UniFET?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Resistance 56MOhm
Terminal Finish Tin (Sn)
Additional Feature FAST SWITCHING
Subcategory FET General Purpose Power
Technology MOSFET (Metal Oxide)
Number of Elements 1
Power Dissipation-Max 500W Tc
Element Configuration Single
Operating Mode ENHANCEMENT MODE
Power Dissipation 500W
Turn On Delay Time 140 ns
FET Type N-Channel
Transistor Application SWITCHING
Rds On (Max) @ Id, Vgs 56m Ω @ 29.5A, 10V
Vgs(th) (Max) @ Id 5V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 4670pF @ 25V
Current - Continuous Drain (Id) @ 25°C 59A Tc
Gate Charge (Qg) (Max) @ Vgs 100nC @ 10V
Rise Time 575 ns
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±30V
Fall Time (Typ) 200 ns
Turn-Off Delay Time 120 ns
Continuous Drain Current (ID) 59A
Threshold Voltage 5V
Gate to Source Voltage (Vgs) 30V
Drain to Source Breakdown Voltage 300V
Nominal Vgs 5 V
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
Alternative Model
