IXTY1N80
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 800V 750MA TO-252AA
PDF
/
Inventory: 7854
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 100 mJ
Pulsed Drain Current-Max (IDM) 3A
Drain to Source Breakdown Voltage 800V
Drain Current-Max (Abs) (ID) 0.75A
Gate to Source Voltage (Vgs) 20V
JEDEC-95 Code TO-252AA
Continuous Drain Current (ID) 750mA
Turn-Off Delay Time 40 ns
Fall Time (Typ) 28 ns
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 10V
Rise Time 19ns
Gate Charge (Qg) (Max) @ Vgs 8.5nC @ 10V
Current - Continuous Drain (Id) @ 25°C 750mA Tc
Input Capacitance (Ciss) (Max) @ Vds 220pF @ 25V
Vgs(th) (Max) @ Id 4.5V @ 25μA
Rds On (Max) @ Id, Vgs 11 Ω @ 500mA, 10V
Transistor Application SWITCHING
FET Type N-Channel
Case Connection DRAIN
Power Dissipation 40W
Operating Mode ENHANCEMENT MODE
Element Configuration Single
Power Dissipation-Max 40W Tc
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PSSO-G2
Pin Count 4
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Technology MOSFET (Metal Oxide)
Additional Feature AVALANCHE RATED
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Published 2003
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 24 Weeks
