TRA2525
RoHS
/
Package Microde Button
Category Discrete Semiconductor Products / Diodes - Rectifiers - Single
Description
DIODE GP 250V 25A MICRODE BUTTON
PDF
/
Inventory: 9012
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 weeks ago)
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case Microde Button
Number of Pins 2
Diode Element Material SILICON
Technical
Packaging Bulk
Published 2010
JESD-609 Code e3
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 2
ECCN Code EAR99
Terminal Finish Tin (Sn)
Max Operating Temperature 175°C
Min Operating Temperature -65°C
HTS Code 8541.10.00.80
Subcategory Rectifier Diodes
Voltage - Rated DC 250V
Terminal Position END
Terminal Form NO LEAD
Peak Reflow Temperature (Cel) NOT SPECIFIED
Reach Compliance Code not_compliant
Current Rating 25A
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 2
Qualification Status Not Qualified
Number of Elements 1
Element Configuration Single
Speed Standard Recovery >500ns, > 200mA (Io)
Diode Type Standard
Current - Reverse Leakage @ Vr 10μA @ 250V
Output Current 25A
Voltage - Forward (Vf) (Max) @ If 1.18V @ 100A
Operating Temperature - Junction -65°C~175°C
Max Surge Current 400A
Application GENERAL PURPOSE
Max Reverse Voltage (DC) 250V
Average Rectified Current 25A
Number of Phases 1
Peak Reverse Current 10μA
Reverse Voltage 250V
Compliance
RoHS Status Non-RoHS Compliant
Lead Free Contains Lead
