IRF7410PBF
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
INFINEON IRF7410PBF MOSFET Transistor, P Channel, 16 A, -12 V, 7 mohm, -4.5 V, -900 mV
PDF
/
Buying Options
Total Price: USD $0.67
Unit Price: USD $0.67165
≥1 USD $0.67165
≥10 USD $0.551
≥100 USD $0.5339
≥500 USD $0.5168
≥1000 USD $0.4997
Inventory: 105434
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
DS Breakdown Voltage-Min 12V
Pulsed Drain Current-Max (IDM) 65A
Drain-source On Resistance-Max 0.007Ohm
Drain Current-Max (Abs) (ID) 16A
JEDEC-95 Code MS-012AA
Vgs (Max) ±8V
Drive Voltage (Max Rds On,Min Rds On) 1.8V 4.5V
Drain to Source Voltage (Vdss) 12V
Gate Charge (Qg) (Max) @ Vgs 91nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 16A Ta
Input Capacitance (Ciss) (Max) @ Vds 8676pF @ 10V
Vgs(th) (Max) @ Id 900mV @ 250μA
Rds On (Max) @ Id, Vgs 7m Ω @ 16A, 4.5V
Transistor Application SWITCHING
FET Type P-Channel
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 2.5W Ta
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G8
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
Subcategory Other Transistors
Additional Feature ULTRA LOW RESISTANCE
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
JESD-609 Code e3
Series HEXFET?
Published 2006
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 12 Weeks
