IPD50N06S2L13ATMA2
RoHS
RoHS compliant
RoHS compliantPackage TO-252-3, DPak (2 Leads + Tab), SC-63
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET N-CH 55V 50A TO252-3
PDF
/
Buying Options
Total Price: USD $1.68
Unit Price: USD $1.68245
≥1 USD $1.68245
≥10 USD $1.3813
≥100 USD $1.3376
≥500 USD $1.29485
≥1000 USD $1.25115
Inventory: 1103
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Avalanche Energy Rating (Eas) 240 mJ
Pulsed Drain Current-Max (IDM) 200A
Drain-source On Resistance-Max 0.0167Ohm
Max Dual Supply Voltage 55V
Continuous Drain Current (ID) 50A
Vgs (Max) ±20V
Drive Voltage (Max Rds On,Min Rds On) 4.5V 10V
Gate Charge (Qg) (Max) @ Vgs 69nC @ 10V
Current - Continuous Drain (Id) @ 25°C 50A Tc
Input Capacitance (Ciss) (Max) @ Vds 1800pF @ 25V
Vgs(th) (Max) @ Id 2V @ 80μA
Rds On (Max) @ Id, Vgs 12.7m Ω @ 34A, 10V
FET Type N-Channel
Case Connection DRAIN
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 136W Tc
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
JESD-30 Code R-PSSO-G2
Reference Standard AEC-Q101
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form GULL WING
Terminal Position SINGLE
Technology MOSFET (Metal Oxide)
Additional Feature ULTRA-LOW RESISTANCE
ECCN Code EAR99
Number of Terminations 2
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
Series OptiMOS?
Published 2002
Packaging Tape & Reel (TR)
Operating Temperature -55°C~175°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-252-3, DPak (2 Leads + Tab), SC-63
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
