BSL207SP
RoHS
/
Package SOT-23-6 Thin, TSOT-23-6
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
MOSFET P-CH 20V 6A 6-TSOP
PDF
/
Buying Options
Total Price: USD $0.1
Unit Price: USD $0.0969
≥1 USD $0.0969
≥10 USD $0.0798
≥100 USD $0.07695
≥500 USD $0.07505
≥1000 USD $0.0722
≥6000 USD $0.0646
Inventory: 30008
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
Avalanche Energy Rating (Eas) 44 mJ
DS Breakdown Voltage-Min 20V
Pulsed Drain Current-Max (IDM) 24A
Drain-source On Resistance-Max 0.041Ohm
Drain Current-Max (Abs) (ID) 6A
Vgs (Max) ±12V
Drive Voltage (Max Rds On,Min Rds On) 2.5V 4.5V
Drain to Source Voltage (Vdss) 20V
Gate Charge (Qg) (Max) @ Vgs 20nC @ 4.5V
Current - Continuous Drain (Id) @ 25°C 6A Ta
Input Capacitance (Ciss) (Max) @ Vds 1007pF @ 15V
Vgs(th) (Max) @ Id 1.2V @ 40μA
Rds On (Max) @ Id, Vgs 41m Ω @ 6A, 4.5V
Transistor Application SWITCHING
FET Type P-Channel
Operating Mode ENHANCEMENT MODE
Power Dissipation-Max 2W Ta
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
JESD-30 Code R-PDSO-G6
Reference Standard AEC-Q101
Pin Count 6
Terminal Form GULL WING
Terminal Position DUAL
Technology MOSFET (Metal Oxide)
HTS Code 8541.29.00.95
Additional Feature AVALANCHE RATED
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 6
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Series OptiMOS?
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Surface Mount YES
Package / Case SOT-23-6 Thin, TSOT-23-6
Mounting Type Surface Mount
