EPC2053
RoHS
RoHS compliant
RoHS compliantPackage Die
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans Gan 100V Die 4MOHM
PDF
/
Buying Options
Total Price: USD $5.77
Unit Price: USD $5.7728
≥1 USD $5.7728
≥10 USD $4.84528
≥100 USD $3.919608
≥500 USD $3.484096
≥1000 USD $2.983253
Inventory: 6571
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Vgs (Max) +6V, -4V
Drive Voltage (Max Rds On,Min Rds On) 5V
Drain to Source Voltage (Vdss) 100V
Gate Charge (Qg) (Max) @ Vgs 14.8nC @ 5V
Current - Continuous Drain (Id) @ 25°C 48A
Input Capacitance (Ciss) (Max) @ Vds 1895pF @ 50V
Vgs(th) (Max) @ Id 2.5V @ 9mA
Rds On (Max) @ Id, Vgs 3.8mOhm @ 25A, 5V
FET Type N-Channel
Technology GaNFET (Gallium Nitride)
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Series eGaN?
Packaging Tape & Reel (TR)
Operating Temperature -40°C~150°C TJ
Physical
Supplier Device Package Die
Package / Case Die
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
