CSD86350Q5D
RoHS
RoHS compliant
RoHS compliantPackage 8-PowerLDFN
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Arrays
Description
Synchronous Buck NexFET Power Block 8-Pin SON EP T/R
PDF
/
Buying Options
Total Price: USD $2.33
Unit Price: USD $2.332
≥1 USD $2.332
≥10 USD $1.93864
≥100 USD $1.542992
≥500 USD $1.305621
≥1000 USD $1.107806
Inventory: 1163
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 6 Weeks
Lifecycle Status ACTIVE (Last Updated: 4 days ago)
Physical
Contact Plating Gold, Tin
Mount Surface Mount
Mounting Type Surface Mount
Package / Case 8-PowerLDFN
Number of Pins 8
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
Series NexFET?
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 9
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Max Power Dissipation 13W
Peak Reflow Temperature (Cel) 260
Number of Functions 1
Terminal Pitch 1.27mm
Base Part Number CSD86350
Pin Count 9
Output Voltage 1.3V
Input Voltage-Nom 12V
Analog IC - Other Type SWITCHING REGULATOR
Element Configuration Dual
Power Dissipation 13W
Turn On Delay Time 9 ns
FET Type 2 N-Channel (Half Bridge)
Input Voltage (Max) 22V
Rds On (Max) @ Id, Vgs 6m Ω @ 20A, 8V
Vgs(th) (Max) @ Id 2.1V @ 250μA
Control Technique PULSE WIDTH MODULATION
Input Capacitance (Ciss) (Max) @ Vds 1870pF @ 12.5V
Gate Charge (Qg) (Max) @ Vgs 10.7nC @ 4.5V
Rise Time 23 ns
Supply Current-Max (Isup) 40mA
Drain to Source Voltage (Vdss) 25V
Fall Time (Typ) 21 ns
Turn-Off Delay Time 24 ns
Switcher Configuration BUCK
Continuous Drain Current (ID) 40A
Threshold Voltage 1.4V
Gate to Source Voltage (Vgs) 8V
Switching Frequency-Max 1500kHz
Drain to Source Breakdown Voltage 25V
FET Feature Logic Level Gate
Nominal Vgs 1.3 V
Dimensions
Height 1.5mm
Length 5mm
Width 6mm
Thickness 1.5mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Contains Lead
