TR136
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 400V 3A TO-220
PDF
/
Buying Options
Total Price: USD $1.15
Unit Price: USD $1.147536
≥1 USD $1.147536
≥10 USD $1.082578
≥100 USD $1.021307
≥500 USD $0.963493
≥1000 USD $0.908956
Inventory: 3134
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
hFE Min 10
Emitter Base Voltage (VEBO) 9V
Collector Emitter Saturation Voltage 700mV
Collector Emitter Breakdown Voltage 400V
Vce Saturation (Max) @ Ib, Ic 1V @ 500mA, 2A
JEDEC-95 Code TO-220AB
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 2A 5V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 400V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application SWITCHING
Power - Max 60W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number TR136
Max Power Dissipation 60W
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Factory Lead Time 8 Weeks
