TIP117
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP DARL 100V 2A TO-220
PDF
/
Buying Options
Total Price: USD $0.44
Unit Price: USD $0.44
≥1 USD $0.44
Inventory: 864
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 4.6mm
Length 10.4mm
Height 9.15mm
Technical
hFE Min 1000
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 100V
Collector Emitter Saturation Voltage 2.5V
Collector Emitter Breakdown Voltage 100V
Vce Saturation (Max) @ Ib, Ic 2.5V @ 8mA, 2A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 2mA
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 1A 4V
Max Collector Current 2A
Collector Emitter Voltage (VCEO) 100V
Transistor Type PNP - Darlington
Transistor Application SWITCHING
Power - Max 2W
Power Dissipation 50W
Element Configuration Single
Polarity PNP
Number of Elements 1
Pin Count 3
Base Part Number TIP117
Current Rating -2A
Max Power Dissipation 2W
Voltage - Rated DC -100V
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Weight 4.535924g
Number of Pins 3
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
