ST901TFP
RoHS
RoHS compliant
RoHS compliantPackage TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistors - BJT PWR BIP/S.SIGNAL
PDF
/
Inventory: 6608
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Collector Emitter Breakdown Voltage 400V
Vce Saturation (Max) @ Ib, Ic 2V @ 1A, 5A
Current - Collector Cutoff (Max) 100μA
DC Current Gain (hFE) (Min) @ Ic, Vce 1500 @ 2A 2V
Max Collector Current 4A
Collector Emitter Voltage (VCEO) 2V
Transistor Type NPN - Darlington
Power - Max 80W
Base Part Number ST901
Max Power Dissipation 80W
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
Packaging Tape & Reel (TR)
Physical
Package / Case TO-220-3 Full Pack
Mounting Type Through Hole
Mount Through Hole
