STW36N60M6
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - FETs, MOSFETs - Single
Description
Trans MOSFET N-CH 600V 30A 3-Pin(3+Tab) TO-247 Tube
PDF
/
Buying Options
Total Price: USD $6.2
Unit Price: USD $6.204
≥1 USD $6.204
≥10 USD $4.95176
≥100 USD $4.43058
≥500 USD $3.909338
≥1000 USD $3.518407
≥3000 USD $3.296876
Inventory: 633
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 16 Weeks
Lifecycle Status ACTIVE (Last Updated: 8 months ago)
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Technical
Operating Temperature -55°C~150°C TJ
Series MDmesh? M6
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Technology MOSFET (Metal Oxide)
Base Part Number STW36N
Power Dissipation-Max 208W Tc
FET Type N-Channel
Rds On (Max) @ Id, Vgs 99m Ω @ 15A, 10V
Vgs(th) (Max) @ Id 4.75V @ 250μA
Input Capacitance (Ciss) (Max) @ Vds 1960pF @ 100V
Current - Continuous Drain (Id) @ 25°C 30A Tc
Gate Charge (Qg) (Max) @ Vgs 44.3nC @ 10V
Drain to Source Voltage (Vdss) 600V
Drive Voltage (Max Rds On,Min Rds On) 10V
Vgs (Max) ±25V
Compliance
RoHS Status ROHS3 Compliant
