BD238
RoHS
RoHS compliant
RoHS compliantPackage TO-225AA, TO-126-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole PNP Single Bipolar (BJT) Transistor 25 @ 1A 2V 100muA ICBO 25W 3MHz
PDF
/
Buying Options
Total Price: USD $0.06
Unit Price: USD $0.05548
≥1 USD $0.05548
≥10 USD $0.05435
≥100 USD $0.053596
≥500 USD $0.2071
≥1000 USD $0.20045
Inventory: 38
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status ROHS3 Compliant
REACH SVHC No SVHC
Radiation Hardening No
Dimensions
Width 2.7mm
Length 7.8mm
Height 10.8mm
Technical
hFE Min 40
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 100V
Collector Emitter Saturation Voltage -600mV
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 600mV @ 100mA, 1A
Current - Collector Cutoff (Max) 100μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 25 @ 1A 2V
Max Collector Current 2A
Collector Emitter Voltage (VCEO) 80V
Transistor Type PNP
Gain Bandwidth Product 3MHz
Power Dissipation 25W
Element Configuration Single
Number of Elements 1
Pin Count 3
Base Part Number BD238
Frequency 3MHz
Current Rating -2A
Max Power Dissipation 25W
Voltage - Rated DC -100V
ECCN Code EAR99
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
Packaging Tube
Operating Temperature 150°C TJ
Physical
Weight 4.535924g
Number of Pins 3
Package / Case TO-225AA, TO-126-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
