2SC3415STPP
RoHS
RoHS compliant
RoHS compliantPackage SC-72 Formed Leads
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Through Hole NPN SINGLE Bipolar (BJT) Transistor 56 @ 10mA 10V 500nA ICBO 300mW 100MHz
PDF
/
Inventory: 9526
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Frequency - Transition 100MHz
Transition Frequency 100MHz
Collector Emitter Breakdown Voltage 300V
Vce Saturation (Max) @ Ib, Ic 2V @ 5mA, 50mA
Current - Collector Cutoff (Max) 500nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 56 @ 10mA 10V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 2V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application AMPLIFIER
Power - Max 300mW
Configuration SINGLE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 10
Peak Reflow Temperature (Cel) 260
Terminal Position SINGLE
Max Power Dissipation 300mW
Subcategory Other Transistors
HTS Code 8541.21.00.95
Terminal Finish TIN SILVER COPPER
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
JESD-609 Code e1
Published 2001
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case SC-72 Formed Leads
Mounting Type Through Hole
Mount Through Hole
