2N4400TF
RoHS
RoHS compliant
RoHS compliantPackage TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Through Hole NPN SINGLE Bipolar (BJT) Transistor 50 @ 150mA 1V 600mA 625mW 255ns
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0264
≥1 USD $0.0264
Inventory: 20048
Minimum: 1
-
+
Technical Details
Physical
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Surface Mount NO
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Tape & Reel (TR)
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
Terminal Finish MATTE TIN
Terminal Position BOTTOM
Terminal Form WIRE
Peak Reflow Temperature (Cel) NOT APPLICABLE
Time@Peak Reflow Temperature-Max (s) NOT APPLICABLE
Pin Count 3
JESD-30 Code O-PBCY-W3
Qualification Status COMMERCIAL
Number of Elements 1
Configuration SINGLE
Power - Max 625mW
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
DC Current Gain (hFE) (Min) @ Ic, Vce 50 @ 150mA 1V
Vce Saturation (Max) @ Ib, Ic 750mV @ 50mA, 500mA
Voltage - Collector Emitter Breakdown (Max) 40V
Current - Collector (Ic) (Max) 600mA
Turn Off Time-Max (toff) 255ns
Turn On Time-Max (ton) 35ns
Compliance
RoHS Status ROHS3 Compliant
