XN09D5800L
RoHS
/
Package SOT-23-6
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 15VCEO 2.5A MINI 6P
PDF
/
Inventory: 6796
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case SOT-23-6
Supplier Device Package MINI6-G1
Technical
Operating Temperature 125°C TJ
Packaging Tape & Reel (TR)
Published 2004
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -15V
Max Power Dissipation 600mW
Current Rating -2.5A
Power - Max 600mW
Transistor Type PNP + Diode (Isolated)
Collector Emitter Voltage (VCEO) 320mV
Max Collector Current 2.5A
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 100mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 320mV @ 50mA, 2.5A
Collector Emitter Breakdown Voltage 15V
Voltage - Collector Emitter Breakdown (Max) 15V
Current - Collector (Ic) (Max) 2.5A
Max Breakdown Voltage 15V
Frequency - Transition 180MHz
Compliance
RoHS Status RoHS Compliant
Lead Free Contains Lead
