DSC7Q0100L
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bipolar Transistors - BJT BIPLR PW TRANS FLAT LEAD 4.5x4.0mm
PDF
/
Inventory: 6096
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Dimensions
Width 2.5mm
Length 4.5mm
Height 1.5mm
Technical
Continuous Collector Current 1A
hFE Min 4000
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 100V
Max Breakdown Voltage 80V
Collector Emitter Saturation Voltage 1.8V
Collector Emitter Breakdown Voltage 80V
Vce Saturation (Max) @ Ib, Ic 1.8V @ 1mA, 1A
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 4000 @ 1A 10V
Max Collector Current 1A
Collector Emitter Voltage (VCEO) 80V
Transistor Type NPN - Darlington
Transistor Application AMPLIFIER
Case Connection COLLECTOR
Element Configuration Single
Polarity NPN
Number of Elements 1
Base Part Number DSC7Q01
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code unknown
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Form FLAT
Max Power Dissipation 1W
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case TO-243AA
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
