DSA300100L
RoHS
RoHS compliant
RoHS compliantPackage SOT-723
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Reel (TR) Surface Mount NPN Single Bipolar (BJT) Transistor 210 @ 2mA 10V 100muA 100mW 150MHz
PDF
/
Buying Options
Total Price: USD $2.8
Unit Price: USD $2.80345
≥1 USD $2.80345
≥10 USD $2.29995
≥100 USD $2.22775
≥500 USD $2.1565
≥1000 USD $2.0843
Inventory: 25564
Minimum: 1
-
+
Technical Details
Technical
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Base Part Number DSA3001
Number of Elements 1
Element Configuration Single
Transistor Application AMPLIFIER
Gain Bandwidth Product 150MHz
Polarity/Channel Type NPN
Transistor Type PNP
Collector Emitter Voltage (VCEO) 500mV
Max Collector Current 100mA
DC Current Gain (hFE) (Min) @ Ic, Vce 210 @ 2mA 10V
Current - Collector Cutoff (Max) 100μA
Vce Saturation (Max) @ Ib, Ic 500mV @ 10mA, 100mA
Collector Emitter Breakdown Voltage 50V
Max Frequency 150MHz
Transition Frequency 150MHz
Collector Emitter Saturation Voltage -500mV
Max Breakdown Voltage 50V
Collector Base Voltage (VCBO) -60V
Emitter Base Voltage (VEBO) -7V
hFE Min 210
Terminal Form FLAT
Terminal Position DUAL
Max Power Dissipation 100mW
HTS Code 8541.21.00.75
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Discontinued
Published 2009
Packaging Tape & Reel (TR)
Operating Temperature 150°C TJ
Dimensions
Height 470μm
Length 1.2mm
Width 800μm
Compliance
REACH SVHC Unknown
RoHS Status RoHS Compliant
Lead Free Lead Free
Physical
Transistor Element Material SILICON
Number of Pins 3
Package / Case SOT-723
Mounting Type Surface Mount
Mount Surface Mount
Supply Chain
Factory Lead Time 10 Weeks
