TIP141G
RoHS
RoHS compliant
RoHS compliantPackage TO-247-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN DARL 80V 10A TO247
PDF
/
Buying Options
Total Price: USD $1.38
Unit Price: USD $1.3832
≥1 USD $1.3832
≥10 USD $1.13525
≥100 USD $1.09915
≥500 USD $1.064
≥1000 USD $1.02885
Inventory: 1278
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 2 Weeks
Lifecycle Status ACTIVE (Last Updated: 3 days ago)
Physical
Mounting Type Through Hole
Package / Case TO-247-3
Surface Mount NO
Number of Pins 3
Weight 6.500007g
Transistor Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tube
Published 2002
JESD-609 Code e3
Pbfree Code yes
Part Status Active
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC 80V
Max Power Dissipation 125W
Peak Reflow Temperature (Cel) 260
Current Rating 10A
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number TIP14*
Pin Count 3
Number of Elements 1
Polarity NPN
Element Configuration Single
Power Dissipation 125W
Case Connection COLLECTOR
Transistor Application SWITCHING
Transistor Type NPN - Darlington
Collector Emitter Voltage (VCEO) 80V
Max Collector Current 10A
DC Current Gain (hFE) (Min) @ Ic, Vce 1000 @ 5A 4V
Current - Collector Cutoff (Max) 2mA
Vce Saturation (Max) @ Ib, Ic 3V @ 40mA, 10A
Collector Emitter Breakdown Voltage 80V
Transition Frequency 4MHz
Collector Emitter Saturation Voltage 2V
Collector Base Voltage (VCBO) 80V
Emitter Base Voltage (VEBO) 5V
hFE Min 1000
Dimensions
Height 12.2mm
Length 15.2mm
Width 4.9mm
Compliance
Radiation Hardening No
REACH SVHC No SVHC
RoHS Status ROHS3 Compliant
Lead Free Lead Free
