SS9014CTA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole NPN Single Bipolar (BJT) Transistor 200 @ 1mA 5V 50nA ICBO 450mW 270MHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8056
≥1 USD $0.8056
≥10 USD $0.6612
≥100 USD $0.6403
≥500 USD $0.62035
≥1000 USD $0.59945
Inventory: 941
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 60
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 50V
Collector Emitter Saturation Voltage 140mV
Collector Emitter Breakdown Voltage 45V
Vce Saturation (Max) @ Ib, Ic 300mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 50nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 1mA 5V
Max Collector Current 100mA
Collector Emitter Voltage (VCEO) 45V
Transistor Type NPN
Gain Bandwidth Product 270MHz
Power Dissipation 450mW
Element Configuration Single
Number of Elements 1
Base Part Number SS9014
Frequency 270MHz
Current Rating 100mA
Max Power Dissipation 450mW
Voltage - Rated DC 45V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tape & Box (TB)
Operating Temperature 150°C TJ
Physical
Weight 240mg
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Mounting Type Through Hole
Mount Through Hole
