SS8550BTA
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tape & Box (TB) Through Hole PNP Single Bipolar (BJT) Transistor 85 @ 100mA 1V 100nA ICBO 1W 200MHz
PDF
/
Buying Options
Total Price: USD $0.02
Unit Price: USD $0.019268
≥1 USD $0.019268
≥500 USD $0.014169
≥1000 USD $0.01181
≥2000 USD $0.010829
≥5000 USD $0.010123
≥10000 USD $0.009419
≥15000 USD $0.009106
≥50000 USD $0.008957
Inventory: 8895
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA) (Formed Leads)
Number of Pins 3
Weight 178.2mg
Technical
Operating Temperature 150°C TJ
Packaging Tape & Box (TB)
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Voltage - Rated DC -25V
Max Power Dissipation 1W
Current Rating -1.5A
Frequency 200MHz
Base Part Number SS8550
Number of Elements 1
Element Configuration Single
Power Dissipation 1W
Gain Bandwidth Product 200MHz
Transistor Type PNP
Collector Emitter Voltage (VCEO) 25V
Max Collector Current 1.5A
DC Current Gain (hFE) (Min) @ Ic, Vce 85 @ 100mA 1V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 80mA, 800mA
Collector Emitter Breakdown Voltage 25V
Collector Emitter Saturation Voltage -280mV
Collector Base Voltage (VCBO) -40V
Emitter Base Voltage (VEBO) -6V
hFE Min 85
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
