MPSA55
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP Single Bipolar (BJT) Transistor 100 @ 100mA 1V 500mA 625mW 50MHz
PDF
/
Buying Options
Total Price: USD $0.15
Unit Price: USD $0.1496
≥1 USD $0.1496
≥10 USD $0.14168
≥100 USD $0.13464
≥500 USD $0.12672
≥1000 USD $0.12408
Inventory: 467
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Number of Pins 3
Supplier Device Package TO-92-3
Weight 201mg
Technical
Operating Temperature -55°C~150°C TJ
Packaging Bulk
Published 2006
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Max Operating Temperature 150°C
Min Operating Temperature -55°C
Voltage - Rated DC -60V
Max Power Dissipation 625mW
Current Rating -500mA
Frequency 50MHz
Base Part Number MPSA55
Number of Elements 1
Polarity PNP
Element Configuration Single
Power Dissipation 625mW
Power - Max 625mW
Gain Bandwidth Product 50MHz
Transistor Type PNP
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 500mA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 100mA 1V
Current - Collector Cutoff (Max) 100nA
Vce Saturation (Max) @ Ib, Ic 250mV @ 10mA, 100mA
Collector Emitter Breakdown Voltage 60V
Voltage - Collector Emitter Breakdown (Max) 60V
Current - Collector (Ic) (Max) 500mA
Collector Emitter Saturation Voltage 250mV
Max Breakdown Voltage 60V
Frequency - Transition 50MHz
Collector Base Voltage (VCBO) 60V
Emitter Base Voltage (VEBO) 4V
hFE Min 100
Compliance
REACH SVHC Unknown
RoHS Status Non-RoHS Compliant
Lead Free Lead Free
