MPS8098
RoHS
/
Package TO-226-3, TO-92-3 (TO-226AA)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN Single Bipolar (BJT) Transistor 100 @ 1mA 5V 100nA 625mW 150MHz
PDF
/
Buying Options
Total Price: USD $0.16
Unit Price: USD $0.1615
≥1 USD $0.1615
≥10 USD $0.133
≥100 USD $0.12825
≥500 USD $0.12445
≥1000 USD $0.12065
≥10000 USD $0.10735
Inventory: 1145
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status Non-RoHS Compliant
Technical
hFE Min 100
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 60V
Max Breakdown Voltage 60V
Collector Emitter Saturation Voltage 400mV
Transition Frequency 150MHz
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 400mV @ 5mA, 100mA
Current - Collector Cutoff (Max) 100nA
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 1mA 5V
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 60V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 150MHz
Transistor Application AMPLIFIER
Power Dissipation 625mW
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Base Part Number MPS8098
Time@Peak Reflow Temperature-Max (s) 30
Frequency 150MHz
Current Rating 500mA
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) 240
Terminal Position BOTTOM
Max Power Dissipation 625mW
Voltage - Rated DC 60V
Subcategory Other Transistors
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Published 2006
Packaging Bulk
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 201mg
Number of Pins 3
Package / Case TO-226-3, TO-92-3 (TO-226AA)
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 2 days ago)
