MJF31C
RoHS
/
Package TO-220-3 Full Pack
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN Single Bipolar (BJT) Transistor 10 @ 3A 4V 300muA 2W 3MHz
PDF
/
Buying Options
Total Price: USD $22.17
Unit Price: USD $22.173
≥1 USD $22.173
≥10 USD $18.19345
≥100 USD $17.6244
≥500 USD $17.0563
≥1000 USD $16.48725
Inventory: 1277
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 week ago)
Physical
Mounting Type Through Hole
Package / Case TO-220-3 Full Pack
Surface Mount NO
Number of Pins 3
Transistor Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Tube
Published 2004
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
Additional Feature UL RECOGNIZED
HTS Code 8541.29.00.95
Subcategory Other Transistors
Voltage - Rated DC 100V
Max Power Dissipation 2W
Peak Reflow Temperature (Cel) 240
Reach Compliance Code not_compliant
Current Rating 3A
hFE Min 25
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 100V
Collector Emitter Saturation Voltage 1.2V
Transition Frequency 3MHz
Collector Emitter Breakdown Voltage 100V
Vce Saturation (Max) @ Ib, Ic 1.2V @ 375mA, 3A
JEDEC-95 Code TO-220AB
Current - Collector Cutoff (Max) 300μA
DC Current Gain (hFE) (Min) @ Ic, Vce 10 @ 3A 4V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 1.2V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 3MHz
Transistor Application SWITCHING
Case Connection ISOLATED
Element Configuration Single
Number of Elements 1
Qualification Status Not Qualified
Pin Count 3
Time@Peak Reflow Temperature-Max (s) 30
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
