KSD1273QYDTU
RoHS
/
Package TO-220-3 Full Pack, Formed Leads
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Tube Through Hole NPN Single Bipolar (BJT) Transistor 500 @ 500mA 4V 100muA 2W 30MHz
PDF
/
Buying Options
Total Price: USD $0.26
Unit Price: USD $0.264
≥1 USD $0.264
Inventory: 1167
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
hFE Min 500
Emitter Base Voltage (VEBO) 6V
Collector Base Voltage (VCBO) 80V
Collector Emitter Saturation Voltage 1V
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 1V @ 50mA, 2A
Current - Collector Cutoff (Max) 100μA
DC Current Gain (hFE) (Min) @ Ic, Vce 500 @ 500mA 4V
Max Collector Current 3A
Collector Emitter Voltage (VCEO) 60V
Transistor Type NPN
Gain Bandwidth Product 30MHz
Power Dissipation 2W
Element Configuration Single
Number of Elements 1
Base Part Number KSD1273
Frequency 30MHz
Current Rating 3A
Max Power Dissipation 2W
Voltage - Rated DC 60V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Packaging Tube
Operating Temperature 150°C TJ
Physical
Number of Pins 3
Package / Case TO-220-3 Full Pack, Formed Leads
Mounting Type Through Hole
Mount Through Hole
