BD13816S
RoHS
/
Package TO-225AA, TO-126-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 60V 1.5A TO-126
PDF
/
Buying Options
Total Price: USD $2.85
Unit Price: USD $2.84525
≥1 USD $2.84525
≥10 USD $2.3351
≥100 USD $2.26195
≥500 USD $2.1888
≥1000 USD $2.1166
Inventory: 1135
Minimum: 1
-
+
Technical Details
Supply Chain
Lifecycle Status OBSOLETE (Last Updated: 1 day ago)
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-225AA, TO-126-3
Number of Pins 3
Weight 761mg
Transistor Element Material SILICON
Technical
Operating Temperature 150°C TJ
Packaging Bulk
JESD-609 Code e3
Pbfree Code yes
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin (Sn)
Subcategory Other Transistors
Voltage - Rated DC -60V
Max Power Dissipation 1.25W
Current Rating -1.5A
Base Part Number BD138
Number of Elements 1
Element Configuration Single
Power Dissipation 1.25W
Transistor Application SWITCHING
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 60V
Max Collector Current 1.5A
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 150mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 50mA, 500mA
Collector Emitter Breakdown Voltage 60V
Collector Emitter Saturation Voltage -500mV
Collector Base Voltage (VCBO) -60V
Emitter Base Voltage (VEBO) -5V
hFE Min 40
Compliance
Radiation Hardening No
RoHS Status RoHS Compliant
Lead Free Lead Free
Alternative Model
