BCW32
RoHS
/
Package TO-236-3, SC-59, SOT-23-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 32V 0.5A SOT-23
PDF
/
Buying Options
Total Price: USD $0.03
Unit Price: USD $0.0285
≥1 USD $0.0285
≥10 USD $0.0228
≥100 USD $0.0228
≥500 USD $0.02185
≥1000 USD $0.0209
≥9000 USD $0.019
Inventory: 9064
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Technical
hFE Min 200
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 32V
Frequency - Transition 200MHz
Collector Emitter Saturation Voltage 250mV
Collector Emitter Breakdown Voltage 32V
Vce Saturation (Max) @ Ib, Ic 250mV @ 500μA, 10mA
Current - Collector Cutoff (Max) 100nA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 200 @ 2mA 5V
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 32V
Transistor Type NPN
Power Dissipation 350mW
Element Configuration Single
Number of Elements 1
Base Part Number BCW32
Current Rating 500mA
Max Power Dissipation 350mW
Voltage - Rated DC 32V
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2005
Packaging Tape & Reel (TR)
Operating Temperature -55°C~150°C TJ
Physical
Weight 30mg
Number of Pins 3
Package / Case TO-236-3, SC-59, SOT-23-3
Mounting Type Surface Mount
Mount Surface Mount
