2SC5242RTU
RoHS
/
Package TO-3P-3, SC-65-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Trans GP BJT NPN 250V 17A 3-Pin(3+Tab) TO-3P Tube
PDF
/
Buying Options
Total Price: USD $1.24
Unit Price: USD $1.2445
≥1 USD $1.2445
≥10 USD $1.02125
≥100 USD $0.9899
≥500 USD $0.9576
≥1000 USD $0.9253
Inventory: 1233
Minimum: 1
-
+
Technical Details
Compliance
Lead Free Lead Free
RoHS Status RoHS Compliant
Radiation Hardening No
Technical
hFE Min 55
Emitter Base Voltage (VEBO) 5V
Collector Base Voltage (VCBO) 250V
Transition Frequency 30MHz
Collector Emitter Breakdown Voltage 250V
Vce Saturation (Max) @ Ib, Ic 3V @ 800mA, 8A
Current - Collector Cutoff (Max) 5μA ICBO
DC Current Gain (hFE) (Min) @ Ic, Vce 55 @ 1A 5V
Max Collector Current 17A
Collector Emitter Voltage (VCEO) 250V
Transistor Type NPN
Polarity/Channel Type NPN
Gain Bandwidth Product 30MHz
Transistor Application AMPLIFIER
Power Dissipation 130W
Element Configuration Single
Number of Elements 1
Base Part Number 2SC5242
Frequency 30MHz
Max Power Dissipation 130W
Subcategory Other Transistors
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code yes
JESD-609 Code e3
Published 2014
Packaging Tube
Operating Temperature -55°C~150°C TJ
Physical
Transistor Element Material SILICON
Weight 6.401g
Number of Pins 3
Package / Case TO-3P-3, SC-65-3
Mounting Type Through Hole
Mount Through Hole
Contact Plating Tin
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 1 week ago)
Factory Lead Time 6 Weeks
