2N3055H
RoHS
/
Package TO-204AA, TO-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS NPN 60V 15A TO-3
PDF
/
Inventory: 1114
Minimum: /
The more specific your information, the faster response you will get.
Please complete the following form with the details of your request part and
contact information to get a quote.
Quotation Consultation
Technical Details
Compliance
Lead Free Contains Lead
RoHS Status Non-RoHS Compliant
REACH SVHC No SVHC
Technical
hFE Min 20
Emitter Base Voltage (VEBO) 7V
Collector Base Voltage (VCBO) 100V
Frequency - Transition 2.5MHz
Collector Emitter Saturation Voltage 1.1V
Current - Collector (Ic) (Max) 15A
Voltage - Collector Emitter Breakdown (Max) 60V
Collector Emitter Breakdown Voltage 60V
Vce Saturation (Max) @ Ib, Ic 3V @ 3.3A, 10A
Current - Collector Cutoff (Max) 700μA
DC Current Gain (hFE) (Min) @ Ic, Vce 20 @ 4A 4V
Max Collector Current 15A
Collector Emitter Voltage (VCEO) 3V
Transistor Type NPN
Gain Bandwidth Product 2.5MHz
Power - Max 115W
Power Dissipation 115W
Element Configuration Single
Polarity NPN
Base Part Number 2N3055
Current Rating 15A
Max Power Dissipation 115W
Voltage - Rated DC 60V
Min Operating Temperature -65°C
Max Operating Temperature 150°C
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Published 2004
Packaging Tray
Operating Temperature -65°C~200°C TJ
Physical
Supplier Device Package TO-204 (TO-3)
Number of Pins 2
Package / Case TO-204AA, TO-3
Mounting Type Through Hole
Mount Through Hole
Supply Chain
Lifecycle Status LAST SHIPMENTS (Last Updated: 2 days ago)
