DCX53-13
RoHS
RoHS compliant
RoHS compliantPackage TO-243AA
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
TRANS PNP 80V 1A SOT89-3
PDF
/
Buying Options
Total Price: USD $0.35
Unit Price: USD $0.352
≥1 USD $0.352
Inventory: 998
Minimum: 1
-
+
Technical Details
Supply Chain
Factory Lead Time 14 Weeks
Physical
Mount Surface Mount
Mounting Type Surface Mount
Package / Case TO-243AA
Number of Pins 4
Weight 130.492855mg
Transistor Element Material SILICON
Technical
Operating Temperature -55°C~150°C TJ
Packaging Cut Tape (CT)
Published 2007
JESD-609 Code e3
Pbfree Code yes
Part Status Discontinued
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 4
ECCN Code EAR99
Terminal Finish Matte Tin (Sn)
Subcategory Other Transistors
Max Power Dissipation 1W
Terminal Position DUAL
Terminal Form FLAT
Peak Reflow Temperature (Cel) 260
Time@Peak Reflow Temperature-Max (s) 40
Base Part Number DCX53
Pin Count 4
Number of Elements 1
Element Configuration Single
Case Connection COLLECTOR
Power - Max 1W
Transistor Application SWITCHING
Gain Bandwidth Product 200MHz
Polarity/Channel Type PNP
Transistor Type PNP
Collector Emitter Voltage (VCEO) 80V
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 63 @ 150mA 2V
Current - Collector Cutoff (Max) 100nA ICBO
Vce Saturation (Max) @ Ib, Ic 500mV @ 50mA, 500mA
Collector Emitter Breakdown Voltage 80V
Transition Frequency 200MHz
Max Breakdown Voltage 80V
Collector Base Voltage (VCBO) 100V
Emitter Base Voltage (VEBO) 5V
hFE Min 63
Dimensions
Height 1.5mm
Length 4.5mm
Width 2.48mm
Compliance
Radiation Hardening No
RoHS Status ROHS3 Compliant
