RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole NPN SINGLE Bipolar (BJT) Transistor 30 @ 300mA 10V 1mA 40W 10MHz
PDF
/
Buying Options
Total Price: USD $0.81
Unit Price: USD $0.8096
≥1 USD $0.8096
≥10 USD $0.76912
≥100 USD $0.72864
≥500 USD $0.68816
≥1000 USD $0.67144
Inventory: 545
Minimum: 1
-
+
Technical Details
Physical
Mount Through Hole
Mounting Type Through Hole
Package / Case TO-220-3
Transistor Element Material SILICON
Technical
Operating Temperature -65°C~150°C TJ
Packaging Bulk
Published 2016
JESD-609 Code e0
Pbfree Code no
Part Status Obsolete
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Number of Terminations 3
ECCN Code EAR99
Terminal Finish Tin/Lead (Sn/Pb)
HTS Code 8541.29.00.95
Subcategory Other Transistors
Max Power Dissipation 40W
Terminal Position SINGLE
Peak Reflow Temperature (Cel) NOT SPECIFIED
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Pin Count 3
JESD-30 Code R-PSFM-T3
Qualification Status Not Qualified
Number of Elements 1
Configuration SINGLE
Case Connection COLLECTOR
Power - Max 40W
Transistor Application SWITCHING
Polarity/Channel Type NPN
Transistor Type NPN
Collector Emitter Voltage (VCEO) 1V
Max Collector Current 1A
DC Current Gain (hFE) (Min) @ Ic, Vce 30 @ 300mA 10V
Current - Collector Cutoff (Max) 1mA
JEDEC-95 Code TO-220AB
Vce Saturation (Max) @ Ib, Ic 1V @ 200mA, 1A
Collector Emitter Breakdown Voltage 400V
Transition Frequency 10MHz
Frequency - Transition 10MHz
Compliance
RoHS Status RoHS Compliant
