TIP135
RoHS
/
Package TO-220-3
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Single
Description
Bulk Through Hole PNP 3 Bipolar (BJT) Transistor 8A 70W 60V 150C
PDF
/
Buying Options
Total Price: USD $0.59
Unit Price: USD $0.58615
≥1 USD $0.58615
≥10 USD $0.4807
≥100 USD $0.46645
≥500 USD $0.45125
≥1000 USD $0.43605
Inventory: 1247
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status Non-RoHS Compliant
Technical
DC Current Gain-Min (hFE) 1000
Current - Collector (Ic) (Max) 8A
Collector Emitter Breakdown Voltage 60V
JEDEC-95 Code TO-220AB
Max Collector Current 8A
Transistor Type PNP - Darlington
Polarity/Channel Type PNP
Case Connection COLLECTOR
Number of Elements 1
Operating Temperature (Max) 150°C
Qualification Status Not Qualified
JESD-30 Code R-PSFM-T3
Pin Count 3
Time@Peak Reflow Temperature-Max (s) NOT SPECIFIED
Reach Compliance Code not_compliant
Peak Reflow Temperature (Cel) NOT SPECIFIED
Terminal Position SINGLE
Max Power Dissipation 70W
Subcategory Other Transistors
HTS Code 8541.29.00.95
Terminal Finish Tin/Lead (Sn/Pb)
ECCN Code EAR99
Number of Terminations 3
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Obsolete
Pbfree Code no
JESD-609 Code e0
Packaging Bulk
Physical
Transistor Element Material SILICON
Package / Case TO-220-3
Mounting Type Through Hole
Mount Through Hole
