MAX2602ESA+
RoHS
RoHS compliant
RoHS compliantPackage 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - RF
Description
Tube Surface Mount NPN SINGLE WITH BUILT-IN DIODE RF Transistor 100 @ 250mA 3V 1.2A 6.4W 11.6dB
PDF
/
Buying Options
Total Price: USD $6.1
Unit Price: USD $6.0984
≥1 USD $6.0984
≥10 USD $5.5924
≥100 USD $5.083936
≥500 USD $4.57556
≥1000 USD $4.194256
≥3000 USD $3.812952
Inventory: 372
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Technical
Noise Figure (dB Typ @ f) 3.3dB @ 836MHz
Current - Collector (Ic) (Max) 1.2A
Voltage - Collector Emitter Breakdown (Max) 15V
Gain 11.6dB
DC Current Gain (hFE) (Min) @ Ic, Vce 100 @ 250mA 3V
Transistor Type NPN
Polarity/Channel Type NPN
Transistor Application AMPLIFIER
Power - Max 6.4W
Configuration SINGLE WITH BUILT-IN DIODE
Number of Elements 1
Qualification Status Not Qualified
Pin Count 8
Base Part Number MAX2602
Time@Peak Reflow Temperature-Max (s) 30
Frequency 1GHz
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Subcategory Other Transistors
Terminal Finish Matte Tin (Sn)
ECCN Code EAR99
Number of Terminations 8
Moisture Sensitivity Level (MSL) 1 (Unlimited)
Part Status Active
Pbfree Code yes
JESD-609 Code e3
Published 2009
Packaging Tube
Operating Temperature 150°C TJ
Physical
Transistor Element Material SILICON
Number of Pins 8
Surface Mount YES
Package / Case 8-SOIC (0.154, 3.90mm Width) Exposed Pad
Mounting Type Surface Mount
Supply Chain
Factory Lead Time 6 Weeks
