ULN2003D1
RoHS
RoHS compliant
RoHS compliantPackage 16-SOIC (0.154, 3.90mm Width)
Category Discrete Semiconductor Products / Transistors - Bipolar (BJT) - Arrays
Description
IC PWR RELAY 7NPN 1:1 16SO
PDF
/
Buying Options
Total Price: USD $0.13
Unit Price: USD $0.13015
≥1 USD $0.13015
≥10 USD $0.10735
≥100 USD $0.10355
≥500 USD $0.1007
≥1000 USD $0.0969
≥10000 USD $0.0874
Inventory: 87511
Minimum: 1
-
+
Technical Details
Compliance
RoHS Status ROHS3 Compliant
Radiation Hardening No
Technical
Collector Emitter Saturation Voltage 1.1V
Current - Collector (Ic) (Max) 500mA
Vce Saturation (Max) @ Ib, Ic 1.6V @ 500μA, 350mA
Current - Collector Cutoff (Max) 50μA
Max Collector Current 500mA
Collector Emitter Voltage (VCEO) 50V
Transistor Type 7 NPN Darlington
Transistor Application SWITCHING
Configuration COMPLEX
Polarity NPN
Number of Elements 7
Output Voltage 50V
Pin Count 16
Base Part Number ULN2003
Time@Peak Reflow Temperature-Max (s) 30
Peak Reflow Temperature (Cel) 260
Terminal Form GULL WING
Terminal Position DUAL
Terminal Finish Nickel/Palladium/Gold (Ni/Pd/Au)
ECCN Code EAR99
Number of Terminations 16
Moisture Sensitivity Level (MSL) 3 (168 Hours)
Part Status Obsolete
JESD-609 Code e4
Packaging Tube
Operating Temperature -20°C~85°C TA
Physical
Transistor Element Material SILICON
Number of Pins 16
Package / Case 16-SOIC (0.154, 3.90mm Width)
Mounting Type Surface Mount
Mount Surface Mount
